Heser Pee Valve Balanced Low Profile
€179.00 tax incl.
( 149,17 € tax excl. )
Availability:
In stock
Reference:
91182
Balanced, low profile p-valve for dry suits of any kind.
Manufactured from a Delrin rod and a neoprene rubber tubing. It is made for ladies and gentelmen use.
Very easy to install.
Comfortable lock down even in the dry suit.
Characteristics:
- Gluing the valve in dry suit is not necessary.
- Leak-proof sealing due to O-ring toward to suit.
- For cleaning, the valve can be removed and assembled in a leak-proofing manner easily.
- The high of the valve inside the suit is only about 13mm, nevertheless the same flow is reached as with well-knows valves.
- The valve in the suit is affixed by five screws and not only with one central thread. Thus the cover cap can be opened without removing the whole valve unintentional. Witch leads to a fatal flooding. Note: The screws are well rounded and do not damage the under suit.
- For the five screws metal threaded bushes are begun into the plastic part, like that the threads are very loadable in the counterpart.
- The valve can be opened and closed with one turn.
- The cover cap has a defined and exact turn stop.
Technical specifications:
- Balanced,
- Flow with 0.5m water gauge (0,05bar corresponds): 2 litres/min,
- Hole diameter: 20mm,
- Height in the suit approx. 13mm,
- Cover cap diameter: 42mm,
- Height outside at the suit approx. 20mm,
Included in delivery:
- 1 x PeeValve inclusive all screws and sealings,
- 0,6m tube 1 x Trox-Screwdriver,
- 1 x Connection fitting (Condom fitting).
Service kits availables.
Made from a DELRIN rod and a Neoprene rubber tube. It is made for use by women and men.
Very easy to install.
Characteristics:
- The collage of the p-valve is necessary step,
- Seals against waterproof suit,
- The valve can be disassembled for easy cleaning and reassembly while maintaining its tightness,
- The height of the valve is only 13mm but still maintains a flow rate equivalent to the best known brands,
- The valve is fixed by 5 screws and not by a single central thread. Thus, the cover can be opened without removing the complete valve, which would lead to a water inlet. Note: the screws are well rounded and do not damage the under suit,
- The valve can be opened and closed in just one turn,
- The hood has a very precise and defined rotation.
Technical Specifications :
- Compensated,
- Flow rate at 0.5m of water (0.05bar): 2 litres/min,
- Diameter of the hole: 20mm,
- Height in the suit approx. 13mm,
- Diameter of the cover: 42mm,
- Height outside the suit approx. 20mm.
Included in the package :
- 1 x P-Valve with screws and gaskets,
- 0.6m tube, 1 x Torx screwdriver,
- 1 x Catheter connection.
Service kits available.
91182
Specific References
- Manufacturer reference
- 2200
Balanced, low profile p-valve for dry suits of any kind.
Manufactured from a Delrin rod and a neoprene rubber tubing. It is made for ladies and gentelmen use.
Very easy to install.
Comfortable lock down even in the dry suit.
Characteristics:
- Gluing the valve in dry suit is not necessary.
- Leak-proof sealing due to O-ring toward to suit.
- For cleaning, the valve can be removed and assembled in a leak-proofing manner easily.
- The high of the valve inside the suit is only about 13mm, nevertheless the same flow is reached as with well-knows valves.
- The valve in the suit is affixed by five screws and not only with one central thread. Thus the cover cap can be opened without removing the whole valve unintentional. Witch leads to a fatal flooding. Note: The screws are well rounded and do not damage the under suit.
- For the five screws metal threaded bushes are begun into the plastic part, like that the threads are very loadable in the counterpart.
- The valve can be opened and closed with one turn.
- The cover cap has a defined and exact turn stop.
Technical specifications:
- Balanced,
- Flow with 0.5m water gauge (0,05bar corresponds): 2 litres/min,
- Hole diameter: 20mm,
- Height in the suit approx. 13mm,
- Cover cap diameter: 42mm,
- Height outside at the suit approx. 20mm,
Included in delivery:
- 1 x PeeValve inclusive all screws and sealings,
- 0,6m tube 1 x Trox-Screwdriver,
- 1 x Connection fitting (Condom fitting).
Service kits availables.
